产品规范 |
设计规范 |
法兰连接 |
结构长度 |
试验与检验 |
压力-温度 |
|
GB/T 12234 |
GB/T9113、JB/T79、HG/T20592 |
GB/T 12221 |
GB/T 13927 、JB/T9092 |
GB/T 12224 |
|
零件名称 |
ZG1Cr18Ni9Ti系列 |
2G00Cr18Ni10系列 |
ZG1Cr18Ni12Mo2Ti系列 |
ZG00Cr17Ni14Mo2系列 |
WCB系列 |
|
阀体/阀盖 |
2G1Cr18Ni9Ti |
ZG00Cr18Ni10 |
ZG1Cr18Ni12Mo2Ti |
ZG00Cr17Ni14Mo2 |
WCB |
|
闸板 |
ZG1Cf18NI9Ti |
ZG00Cr18Ni10 |
ZG1Cr18Ni12Mo2Ti |
ZG00Cr17Ni14Mo2 |
1Cr13 |
|
阀杆 |
1Cr18Ni9Ti |
ooCr18Ni10 |
1Cr18Nil2Mo2Ti |
Cr17Ni14Mo2 |
1Cr13 |
|
填料 |
PTFE编织 |
PTFE编织 |
PTFE编织 |
PTFE编织 |
石墨 |
|
垫片 |
304L+PTFE |
304L+PTFE |
316L+PTFE |
316L+PTFE |
石墨+304 Graphite+304 |
|
压盖 |
ZG1Cr181Ni10 |
ZG00Cr18Ni10 |
ZG1Cr18Ni12Mo2Ti |
ZG00Cr17Ni14Mo2 |
WCB |
|
填料压环 |
1Cr18Ni9Ti |
00Cr18Ni10 |
1Cr18Mi12Mo2Ti |
00Cr17Ni14Mo2 |
1Cr13 |
|
螺栓 |
1Cr171Ni2 |
1Cr171Ni2 |
1Cr171Ni2 |
1Cr171Ni2 |
35CrMoA |
|
蜾母 |
1Cr18Ni9Ti |
1Cr18Ni9Ti |
1Cr18Ni9Ti |
1Cr18Ni9Ti |
45 |
|
DN |
L |
L1 |
D |
D1 |
D2 |
B |
Z-d |
H |
D0 |
WT(Kg) |
|
BZ41H-16C BZ41W-16P/R/PL/RL |
||||||||||
|
40 |
200 |
70 |
160 |
125 |
100 |
18 |
4-Φ18 |
310 |
200 |
49 |
|
50 |
250 |
80 |
180 |
145 |
120 |
18 |
4-Φ18 |
358 |
240 |
54 |
|
65 |
270 |
90 |
195 |
160 |
135 |
20 |
8-Φ18 |
373 |
240 |
81 |
|
80 |
280 |
100 |
215 |
180 |
155 |
20 |
8-Φ18 |
435 |
280 |
100 |
|
100 |
300 |
100 |
245 |
210 |
185 |
22 |
8-Φ18 |
500 |
300 |
120 |
|
125 |
325 |
110 |
280 |
240 |
210 |
24 |
8-Φ23 |
614 |
320 |
210 |
|
150 |
350 |
120 |
335 |
295 |
265 |
26 |
12-Φ23 |
674 |
360 |
260 |
|
200 |
400 |
130 |
405 |
355 |
320 |
30 |
12-Φ25 |
818 |
400 |
300 |
|
250 |
450 |
140 |
460 |
410 |
375 |
30 |
12-Φ25 |
969 |
450 |
400 |
|
300 |
500 |
160 |
520 |
470 |
435 |
34 |
16-Φ25 |
1145 |
560 |
490 |
|
BZ41H-25C BZ41W-25P/R/PL/RL |
||||||||||
|
40 |
200 |
70 |
160 |
125 |
100 |
20 |
4-Φ18 |
358 |
240 |
52 |
|
50 |
250 |
80 |
180 |
145 |
120 |
22 |
8-Φ18 |
373 |
240 |
56 |
|
65 |
270 |
90 |
195 |
160 |
135 |
22 |
8-Φ18 |
435 |
280 |
86 |
|
80 |
280 |
100 |
230 |
190 |
160 |
24 |
8-Φ18 |
^500 |
300 |
105 |
|
100 |
300 |
100 |
270 |
220 |
188 |
28 |
8-Φ15 |
614 |
320 |
170 |
|
125 |
325 |
110 |
300 |
250 |
218 |
30 |
8-Φ25 |
674 |
360 |
245 |
|
150 |
350 |
120 |
360 |
310 |
278 |
34 |
12-Φ25 |
818 |
400 |
270 |
|
200 |
400 |
130 |
425 |
370 |
332 |
36 |
12-Φ30 |
969 |
450 |
380 |
|
250 |
450 |
140 |
485 |
430 |
390 |
40 |
12-Φ30 |
1145 |
560 |
535 |
|
300 |
500 |
160 |
550 |
490 |
448 |
44 |
16-Φ34 |
1145 |
640 |
546 |
