序号 |
名称 |
Part Name |
序号 |
名称 |
Part Name |
|
01 |
阀体 |
Body |
14 |
限位块 |
Limit block |
|
02 |
阀盖 |
Bonnet |
15 |
内六角螺钉 |
Socket head cap screw |
|
03 |
阀瓣 |
Disc |
16 |
填料压套 |
Packing gland set |
|
04 |
阀座 |
Seat |
17 |
填料压板 |
Packing pressure plate |
|
05 |
中法兰垫片 |
Flange gasket |
18 |
活节螺栓 |
Eyelet bolt |
|
06 |
阀杆 |
Stem |
19 |
螺母 |
Nut |
|
07 |
阀瓣盖 |
Disc bonnet |
20 |
圆柱销 |
Cylindrical pin |
|
08 |
上密封座 |
Upper seal seat |
21 |
阀杆螺母 |
Stem Nut |
|
09 |
填料 |
Packing |
22 |
推力轴承 |
Thrust bearing |
|
10 |
隅环 |
Every ring |
23 |
锁紧螺母 |
Lock nut |
|
11 |
阀瓣垫 |
Disc mat |
24 |
油杯 |
Oil cup |
|
12 |
螺母 |
Nut |
25 |
锥齿轮部件 |
Bevel gear parts |
|
13 |
螺柱 |
Stud |
一 |
一 |
一 |
